Anchor by Panasonic UNO 20 Amp Single Pole C Curve MCB | ISI Marked Single Pole 10A Miniature Circuit Breaker (98004)
13 sold in last 24 hours
- Certificates: UNO MCB is ISI marked as per IS/IEC 60898-1:2002. The third party tests are done at CPRI, ERDA. A design registration patent is also registered.
- IP 20 Degree Protection: Finger proof terminals eliminate chances of accidental contact with live parts. All the live parts are shrouded/ inaccessible; ensuring safety of installers.
- Positive Contact Indication: UNO MCB has a clearly visible contact position indicator to identify the real positions of contacts inside the MCB.
- Large Termination Size and Dual Termination: UNO MCB has a high terminal capacity of 35 sq.mm that allows using Aluminium conductors or bus- bars for connection & Bi- Connect termination that allows connection of either cable or bus - bar for better flexibility.
- Breaking Capacity 10kA: The Breaker can break high Short Circuit fault under the conditions of 3 phase fault or phase - Neutral fault, voltage dip. The UNO MCB can protect equipment by opening the contacts even if the high current of 10kA appears.
Estimated shipping
Select a product to estimate shipping.The Anchor UNO 20A Single Pole MCB offers reliable protection for your electrical circuits. Designed for safety and ease of use, this MCB is a solid addition to any home or workshop.
Key Highlights
- ISI Marked: Meets Indian Standards (IS/IEC 60898-1:2002) for quality assurance.
- Finger Proof Terminals: Provides enhanced safety by preventing accidental contact with live parts.
- Clear Contact Indication: Easily identify the contact positions for accurate circuit monitoring.
- High Termination Capacity: Accommodates large conductors (up to 35 sq.mm) for flexible connections.
- 10kA Breaking Capacity: Offers robust protection against high-current short circuits.
Useful Facts
- Brand: Anchor by Panasonic
- Current Rating: 20 Amps
- Poles: Single Pole
- Protection Degree: IP 20
- Certifications: ISI Marked, tested by CPRI and ERDA, registered design patent
Good Fit For
- Home electrical installations
- Workshop and garage circuits
- Small commercial applications
- DIY electrical projects
| Main Specification | |
|---|---|
| Fabricante | 022 41304130, Anchor by Panasonic |
| Número de unidades | 1 Contagem |
| Classificação atual | 20 Amps |
| Marca | ANCHOR |
| Número de itens | 1 |
| Tipo de disjuntor | Padrão |
| Componentes Incluídos | MCB |
| Dimensões do produto | 41.5D x 37.5W x 22.5H Centimeters |
| Tipo de Montagem | Montagem de trilhos DIN |
| Peso do Item | 115 Grams |
| Technical Details | |
| Número da parte | FE_98004 |
| País de origem | Índia |
| Número de poloneses | 1 |
| Número de modelo | FE_98004 |
| Item details | |
| Nome do Tipo de Item | 1 Pcs. 20A Single Pole uno Series MCB |
| Measurements | |
| Dimensões do Item D x W x H | 41.5D x 37.5W x 22.5H Centimeters |
| Others | |
| Informações de Contato do Packer | 3o andar or Panasonic Life Solution India Pvt. Ltd. or Asa B or Acho que o Campus Techno or Estrada Pokhran n.o 2 Thane -400607 or 022-41304130 |
| Tipo de produto | 1 Pcs. 20A Single Pole uno Series MCB |
| Informação de Contacto do Importador | Panasonic Life Solutions India Pvt Ltd |
| Informações de contato do fabricante | 022 41304130 |
